Product Advantage
● Machine can print fast , using small area, can instead of the traditional large long screen printing machine to save factory area, save electronic, using less employee, less time and less material.
● The printed label is bright-coloured, stereoscopic and high colour durability. Above all, it is easier operated.
● The frames can move precisely to adjust the position, it also can adjust the position and change the material during the machine working, did not need to stop the machine.
Technical Parameters
| Printing area | 500mm * 260mm |
| Speed | 0~8m/min |
| Power | 220V/8Kw |
| Print material | ribbon, nylon tape, cotton tape, hang tape、PVC and bag material and so on. |
| Machine size | 500*85*90cm |
| Net weight | 750Kg |
Product Uses
● Textile & Apparel: Printing on ribbons, nylon tapes, cotton tapes, and hang tapes.
● Packaging: PVC and bag materials for product branding.
● Accessories: Label printing for elastic bands, decorative tapes, hat brims.
● Industrial Use: Non-woven fabrics, functional tapes requiring durable and precise logos
Product Operate Guide
● Setup – Install the screen frame, adjust the position precisely.
● Load Material – Place ribbon, tape, or PVC material into the machine.
● Parameter Setting – Set printing length, speed, pulling frequency, and number of prints via digital control.
● Ink Preparation – Choose appropriate ink type based on material and effect required.
● Start Printing – Activate the servo system for stable feeding, printing, and drying.
● Drying – Infrared + hot wind system ensures prints dry instantly.
● Quality Check – Inspect print alignment and color fastness; adjust frame positions if needed.
FAQ
Q1: What materials can this machine print on?
A: Ribbons, nylon tapes, cotton tapes, PVC, bag materials, and other similar fabrics.
Q2: How many colors can it print at once?
A: It supports two-color printing on one side, or one color on the front and one color on the back with the ribbon turnover unit.
Q3: Is it suitable for small workshops?
A: Yes, the compact size replaces bulky traditional machines, saving space and labor.
Q4: What drying system does it use?
A: Infrared + hot wind double drying system for fast, reliable curing.
Q5: Can I change material during operation?
A: Yes, you can adjust the frame position and change materials without stopping the machine.
Q6: What’s the printing precision?
A: Digital servo control ensures stable feeding and precise print length, avoiding deviation.
Q7: What inks are supported?
A: Heat-firm, silicone, solvent-based, water slurry, mortar slurry, and traditional screen inks.
